AR0135CS2M25SUEA0-DPBR2
ActiveON Semiconductor
1MP 1/3 CIS SO
AR0135CS2M25SUEA0-DPBR2
ActiveON Semiconductor
1MP 1/3 CIS SO
Description
General part information
AR0135CS2M25SUEA0-DPBR2
CMOS Image Sensor 1280H x 720V 3.75µm x 3.75µm 63-IBGA (9x9)
Technical Specifications
Parameters and characteristics for this part
| Specification | AR0135CS2M25SUEA0-DPBR2 |
|---|---|
| Active Pixel Array Horizontal | 1280 pixels |
| Active Pixel Array Vertical | 720 pixels |
| Frames per Second | 60 fps |
| Package / Case | 63-LBGA |
| Package Length | 9 mm |
| Package Name | 63-IBGA |
| Package Width | 9 mm |
| Pixel Size (Length) | 3.75 µm |
| Pixel Size (Width) | 3.75 µm |
| Type | CMOS |
