B33331I6505J080
ActiveEPCOS - TDK Electronics
5UF 450V AL 30*55 S2 2+2
B33331I6505J080
ActiveEPCOS - TDK Electronics
5UF 450V AL 30*55 S2 2+2
Description
General part information
B33331I6505J080
5 µF Film Capacitor 450V Polypropylene (PP), Metallized Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | B33331I6505J080 |
|---|---|
| Applications | Motor Run |
| Capacitance | 5 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 2.244 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 1.181 in |
| Termination | Quick Connect |
| Termination Probe Tip OD | 0.25 in |
| Tolerance | 5 % |
| Voltage Rating - AC | 450 V |
