R5F113 Series

Part	Peripherals	EEPROM Size (Width)	EEPROM Size (Depth)	Connectivity	Mounting Type	Core Size (Bit Width)	Speed	Program Memory Depth	Program Memory Width	Program Memory Size	Voltage - Supply (Vcc/Vdd) Minimum	Voltage - Supply (Vcc/Vdd) Maximum	Oscillator Type	Core Processor	A/D Resolution (bits)	A/D Channels	RAM Size Depth	RAM Size Width	Package Width	Package Name	Package Length	Operating Temperature (Max)	Operating Temperature (Min)	Program Memory Type
Renesas Electronics Corporation R5F1096EJSP#H0	DMA LVD POR PWM WDT	8 bit	4 K	CSI I2C LINbus UART USART	Surface Mount	16 Bit	32 MHz	64 K	8 bit	64 KB	1.8 V	5.5 V	Internal	RL78	8 bit 10 bit	4 count	4 K	8 bit	6.1 mm	20-LSSOP	0.24 in	85 °C	-40 °C	FLASH

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
