1150816
ActivePhoenix Contact
HOUSING, 2POS, 2.54MM, BLACK ROHS COMPLIANT: YES
1150816
ActivePhoenix Contact
HOUSING, 2POS, 2.54MM, BLACK ROHS COMPLIANT: YES
Description
General part information
1150816
2 Position Terminal Block Plug Housing for Female Sockets 180° Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | 1150816 |
|---|---|
| Color | Black |
| Insulation Height | 0.306 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Levels | 1 |
| Number of Positions | 2 |
| Plug Wire Entry Angle | 180 ° |
| Positions Per Level | 1 |
| Termination Style | Crimp |
| Type | Plug Housing for Female Sockets |
