B25620B167K881
ActiveEPCOS - TDK Electronics
CAP FILM 160UF 10% 880VDC RADIAL
B25620B167K881
ActiveEPCOS - TDK Electronics
CAP FILM 160UF 10% 880VDC RADIAL
Description
General part information
B25620B167K881
160 µF Film Capacitor 880V Polypropylene (PP), Metallized Radial, Can
Technical Specifications
Parameters and characteristics for this part
| Specification | B25620B167K881 |
|---|---|
| Applications | DC Filtering, DC Link |
| Capacitance | 160 µF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 2.795 in |
| Lead Spacing | 1.26 in |
| Mounting Type | Chassis, Stud Mount |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 2.953 in |
| Termination | Threaded, Female |
| Tolerance | 10 % |
| Voltage Rating - DC | 880 V |
