EN91F8
UnknownEnergizer Battery Company
BATTERY PACK ALKALINE 12V AA
EN91F8
UnknownEnergizer Battery Company
BATTERY PACK ALKALINE 12V AA
Description
General part information
EN91F8
AA 12 V Alkaline Manganese Dioxide Battery Pack
Technical Specifications
Parameters and characteristics for this part
| Specification | EN91F8 |
|---|---|
| Battery Cell Size | AA |
| Battery Chemistry | Alkaline Manganese Dioxide |
| Number of Cells | 8 |
| Rechargeability | No |
| Size / Dimension Height | 1.99 in |
| Size / Dimension Length | 4.57 in |
| Size / Dimension Width | 0.57 in |
| Structure | Side to Side |
| Structure Cells | 8 |
| Structure Rows | 1 |
| Termination Style | Solder Tab |
| Voltage - Rated | 12 VAC |
| Weight | 181.44 g |
