TVM06DS-25L-10T
ActiveAmphenol Aerospace Operations
MATRIX 38999, TRI-START SERIES I
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TVM06DS-25L-10T
ActiveAmphenol Aerospace Operations
MATRIX 38999, TRI-START SERIES I
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TVM06DS-25L-10T | TVM06DS Series |
|---|---|---|
| Connector Type | Plug Housing | Plug Housing |
| Contact Shape | Circular | Circular |
| Contact Size | 8 | 4 - 16 |
| Contact Type | Crimp | Crimp |
| Features | Coupling Nut | Coupling Nut |
| Housing Color | Silver | Silver |
| Mounting Type | Free Hanging (In-Line) | Free Hanging (In-Line) |
| Note | Contacts Not Included; Insert Not Included | Contacts Not Included; Insert Not Included |
| Number of Positions | - | 3 - 6 |
| Orientation | N | N |
| Qualification | MIL-DTL-38999 Series III | MIL-DTL-38999 Series III |
| Shell Finish | Nickel | Nickel |
| Shell Material | Aluminum Alloy | Aluminum Alloy |
| Shell Size - Insert | 25L-10 | 25L-10, 25L-22, 23L-22, 23L-2, 37-17 |
| Shell Size - Insert | - | 33 |
| Shell Size - Insert | - | 22 |
| Shielding | Unshielded | Unshielded |
| Type | For Female Sockets | For Female Sockets |
TVM06DS Series
MATRIX 38999, TRI-START SERIES I
| Part | Shell Finish | Note | Contact Shape | Features | Orientation | Contact Size | Mounting Type | Housing Color | Contact Type | Shielding | Type | Connector Type | Shell Size - Insert | Qualification | Shell Material | Number of Positions | Shell Size - Insert [Min] | Shell Size - Insert [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol Aerospace Operations TVM06DS-25L-10R | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 8 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 25L-10 | MIL-DTL-38999 Series III | Aluminum Alloy | |||
Amphenol Aerospace Operations TVM06DS-25L-22T | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 8 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 25L-22 | MIL-DTL-38999 Series III | Aluminum Alloy | 4 | ||
Amphenol Aerospace Operations TVM06DS-23L-22T | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 8 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 23L-22 | MIL-DTL-38999 Series III | Aluminum Alloy | 4 | ||
Amphenol Aerospace Operations TVM06DS-23L-2T | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 8 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 23L-2 | MIL-DTL-38999 Series III | Aluminum Alloy | 3 | ||
Amphenol Aerospace Operations TVM06DS-33-22R | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 4, 16 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | MIL-DTL-38999 Series III | Aluminum Alloy | 6 | 33 | 22 | |
Amphenol Aerospace Operations TVM06DS-37-17R | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 4 4 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 37-17 | MIL-DTL-38999 Series III | Aluminum Alloy | 4 | ||
Amphenol Aerospace Operations TVM06DS-33-22T | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 4, 16 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | MIL-DTL-38999 Series III | Aluminum Alloy | 6 | 33 | 22 | |
Amphenol Aerospace Operations TVM06DS-25L-10T | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 8 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 25L-10 | MIL-DTL-38999 Series III | Aluminum Alloy | |||
Amphenol Aerospace Operations TVM06DS-37-17T | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 4 4 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 37-17 | MIL-DTL-38999 Series III | Aluminum Alloy | 4 | ||
Amphenol Aerospace Operations TVM06DS-25L-22R | Nickel | Contacts Not Included; Insert Not Included | Circular | Coupling Nut | N | 8 | Free Hanging (In-Line) | Silver | Crimp | Unshielded | For Female Sockets | Plug Housing | 25L-22 | MIL-DTL-38999 Series III | Aluminum Alloy | 4 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 522.70 | |
Description
General part information
TVM06DS Series
7 (Power) Position Circular Connector Plug Housing Free Hanging (In-Line) Coupling Nut
