Specification	0190670040

Color	Red
Contact Finish	Electro-Tin
Contact Material	Copper
Features	Brazed Seam
Insulation	Insulated
Insulation Diameter	0.35 in
Length - Overall	1.34 in
Material - Insulation	Polyamide, PA, Nylon
Mounting Type	Free Hanging (In-Line)
Stud/Tab Size	10 Stud
Terminal Type	Circular
Termination	Crimp
Thickness	0.045 in
Width - Outer Edges	0.374 in
Wire Gauge	8 AWG

019067 Series

...

Part	Stud/Tab Size	Termination	Contact Finish	Features	Insulation	Wire Gauge	Mounting Type	Width - Outer Edges	Length - Overall	Contact Material	Color	Thickness	Terminal Type	Insulation Diameter	Material - Insulation	Stud/Tab Size	Stud/Tab Size (Type)
Molex 0190670001	6 Stud	Crimp	Electro-Tin	Brazed Seam	Insulated	8 AWG	Free Hanging (In-Line)	0.468 in	1.39 in	Copper	Red	0.045 in	Circular	0.35 in	Nylon PA Polyamide
Molex 0190670028	0.5 Stud	Crimp	Electro-Tin	Brazed Seam	Insulated	8 AWG	Free Hanging (In-Line)	0.81 in	1.811 in	Copper	Red	0.05 in	Circular	0.35 in	Nylon PA Polyamide
Molex 0190670008	0.25 Stud	Crimp	Electro-Tin	Brazed Seam	Insulated	8 AWG	Free Hanging (In-Line)	0.468 in	1.39 in	Copper	Red	0.045 in	Circular	0.35 in	Nylon PA Polyamide
Molex 0190670091	0.25 Stud	Crimp	Electro-Tin	Brazed Seam	Insulated	2 AWG	Free Hanging (In-Line)	0.879 in	2.303 in	Copper	Red	0.075 in	Circular	0.6 in	Nylon PA Polyamide
Molex 0190670087	0.625 in	Crimp	Electro-Tin	Brazed Seam	Insulated	4 AWG	Free Hanging (In-Line)	0.885 in	2.531 in	Copper	Yellow	0.07 in	Circular	0.51 in	Nylon PA Polyamide	5 Stud 8 Stud
Molex 0190670093	0.3125 in	Crimp	Electro-Tin	Brazed Seam	Insulated	2 AWG	Free Hanging (In-Line)	0.879 in	2.303 in	Copper	Red	0.075 in	Circular	0.6 in	Nylon PA Polyamide	16 Stud 5 Stud	Stud
Molex 0190670338	0.25 Stud	Crimp	Electro-Tin	Brazed Seam	Insulated	8 AWG	Free Hanging (In-Line)	0.468 in	1.39 in	Copper	Red	0.045 in	Circular	0.35 in	Nylon PA Polyamide
Molex 0190670103	0.25 Stud	Crimp	Electro-Tin	Brazed Seam	Insulated	1/0 AWG	Free Hanging (In-Line)	0.84 in	2.628 in	Copper	Blue	0.075 in	Flat Sided	0.68 in	Nylon PA Polyamide
Molex 0190670121	0.4375 in	Crimp	Electro-Tin	Brazed Seam	Insulated	3/0 AWG	Free Hanging (In-Line)	1.067 in	3.008 in	Copper	Red	0.091 in	Flat Sided	0.87 in	Nylon PA Polyamide	16 Stud 7 Stud
Molex 0190670124	0.375 in	Crimp	Electro-Tin		Insulated	4/0 AWG	Free Hanging (In-Line)	1.135 in	3.08 in	Copper	Blue	0.102 in	Circular	0.944 in	Nylon 6/6 PA66 Polyamide	3 Stud 8 Stud
