Specification	1200060559

1st Connector Gender	Male Pins
1st Connector Mounting Type	Free Hanging (In-Line)
1st Connector Number of Positions	5 positions
1st Connector Number of Positions Loaded	4 positions
1st Connector Orientation	Keyed
1st Connector Shell Size - Insert	M12
1st Connector Type	Receptacle
2nd Connector Type	Wire Leads
Assembly Configuration	Standard
Cable Material	Polyvinyl Chloride (PVC)
Cable Type	Round
Color	Black
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Length	3.28 ft
Shielding	Unshielded
Usage	Industrial Environments

120006 Series

Micro-Change (M12) Single-Ended Cordset, 4 Poles, Female (90°) to Pigtail with PNP LED Sensors, 0.34mm² PVC Cable, 5.0m (16.40') Length

...

Part	Shielding	Cable Material	Assembly Configuration	Usage	1st Connector Gender	1st Connector Shell Size - Insert	1st Connector Number of Positions	1st Connector Orientation	Cable Type	1st Connector Mounting Type	1st Connector Type	Ingress Protection Description	Ingress Protection IP Rating	2nd Connector Type	1st Connector Number of Positions Loaded	Color	Length	1st Connector Number of Positions Loaded	2nd Connector Shell Size - Insert (Code)	2nd Connector Orientation	2nd Connector Number of Positions Loaded	2nd Connector Gender	2nd Connector Mounting Type	2nd Connector Number of Positions
Molex 1200061975	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Male Pins	M12	4 positions	Keyed	Round	Free Hanging (In-Line)	Receptacle Right Angle	Dust Tight Waterproof	IP67	Wire Leads	All	Black	6.56 ft
Molex 1200061633	Unshielded	Polyurethane (PUR) Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Male Pins	M12	4 positions		Round	Free Hanging (In-Line)	Receptacle	Dust Tight Waterproof	IP67	Wire Leads	All	Black	3.28 ft
Molex 1200060023	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Female Sockets	M12	4 positions 5 positions	Keyed	Round	Free Hanging (In-Line)	Plug Right Angle	Dust Tight Waterproof	IP67	Wire Leads	All	Black	32.8 ft	4 positions
Molex 1200060654	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Female Sockets	M12	5 positions	Keyed	Round	Free Hanging (In-Line)	Plug Right Angle	Dust Tight Waterproof	IP67	Wire Leads	All	Black	16.4 ft
Molex 1200060049	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Male Pins	M12	4 positions	Keyed	Round	Free Hanging (In-Line)	Receptacle	Dust Tight Waterproof	IP67	Plug	All	Black	16.4 ft		M12	Keyed	All	Female Sockets	Free Hanging (In-Line)	4
Molex 1200060001	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Female Sockets	M12	3 positions		Round	Free Hanging (In-Line)	Plug	Dust Tight Waterproof	IP67	Wire Leads	All	Black	6.56 ft
Molex 1200064256	Unshielded	Polyurethane (PUR)	Standard	Industrial Environments	Female Sockets	M12	3 positions	X	Round	Free Hanging (In-Line)	Plug	Dust Tight Waterproof	IP67	Wire Leads	All	Orange	6.56 ft
Molex 1200060009	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Female Sockets	M12	5 positions	Keyed	Round	Free Hanging (In-Line)	Plug Right Angle	Dust Tight Waterproof	IP67	Wire Leads		Black	32.8 ft	3 positions
Molex 1200060489	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Female Sockets	M12	4 positions	X	Round	Free Hanging (In-Line)	Plug Right Angle	Dust Tight Waterproof	IP67	Wire Leads	All	Black	98.4 ft
Molex 1200060649	Unshielded	Polyvinyl Chloride (PVC)	Standard	Industrial Environments	Female Sockets	M12	5 positions	Keyed	Round	Free Hanging (In-Line)	Plug	Dust Tight Waterproof	IP67	Wire Leads	All	Black	32.8 ft
