HBLE042A-1R0MS
ActiveDelta Electronics/Cyntec
IND SMD 1.0UH MOLDING CHOKE
HBLE042A-1R0MS
ActiveDelta Electronics/Cyntec
IND SMD 1.0UH MOLDING CHOKE
Description
General part information
HBLE042A-1R0MS
1 µH Unshielded Molded Inductor 9 A 11.5mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | HBLE042A-1R0MS |
|---|---|
| Current - Saturation (Isat) | 6 A |
| Current Rating | 9 A |
| DC Resistance (DCR) (Max) | 11.5 mOhm |
| Height - Seated (Max) | 0.083 in |
| Inductance | 1 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.161 in |
| Size / Dimension Width | 0.161 in |
| Tolerance | 20 % |
| Type | Molded |
