R2E160-AY47-10
Obsoleteebm-papst Inc.
AC BACKWARD-CURVED MOTORIZED IMPELLER
R2E160-AY47-10
Obsoleteebm-papst Inc.
AC BACKWARD-CURVED MOTORIZED IMPELLER
Description
General part information
R2E160-AY47-10
Fan Motorized Impellers 230VAC Round - 160mm Dia Ball 4 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | R2E160-AY47-10 |
|---|---|
| Approval Agency | UL, CSA |
| Bearing Type | Ball |
| Current Rating | 1.27 A |
| Fan Type | Motorized Impellers |
| Features | Thermal Overload Protection (TOP), Capacitor |
| Ingress Protection | IP44 |
| Material - Blade | Steel |
| Operating Temperature (Max) | 95 °F |
| Operating Temperature (Min) | -13 °F |
| Power (Watts) | 290 W |
| RPM | 2200 RPM |
| Size / Dimension Diameter | 160 mm |
| Size / Dimension Shape | Round |
| Static Pressure | 0.401 in H2O |
| Termination | 4 Wire Leads |
| Termination Leads Count | 4 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 230 VAC |
| Width | 97.5 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
