KBU1004-G

Active

Comchip Technology

BRIDGE RECT 1PHASE 400V 10A KBU

Search across all available documentation for this part.

Active

Comchip Technology

BRIDGE RECT 1PHASE 400V 10A KBU

Technical Specifications

Parameters and characteristics for this part

Specification	KBU1004-G

Current - Average Rectified (Io)	10 A
Current - Reverse Leakage @ Vr	10 µA
Diode Type	Single Phase
Mounting Type	Through Hole
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-55 °C
Package / Case	KBU, 4-SIP
Supplier Device Package	KBU
Technology	Standard
Voltage - Forward (Vf) (Max) @ If	1 V
Voltage - Peak Reverse (Max) [Max]	400 V

BRIDGE RECT 1PHASE 400V 10A KBU

Part	Current - Average Rectified (Io)	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Diode Type	Technology	Current - Reverse Leakage @ Vr	Voltage - Forward (Vf) (Max) @ If	Mounting Type	Supplier Device Package	Voltage - Peak Reverse (Max) [Max]
Comchip Technology KBU1004-G	10 A	-55 °C	150 °C	4-SIP, KBU	Single Phase	Standard	10 µA	1 V	Through Hole	KBU	400 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Bridge Rectifier Single Phase Standard 400 V Through Hole KBU
