PC0403-681K-RC
ActiveAllied Components International
680UH 10% POWER CHIP INDUCTOR
PC0403-681K-RC
ActiveAllied Components International
680UH 10% POWER CHIP INDUCTOR
Description
General part information
PC0403-681K-RC
680 µH Unshielded Wirewound Inductor 180 mA 10Ohm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PC0403-681K-RC |
|---|---|
| Current Rating | 0.18 A |
| DC Resistance (DCR) (Max) | 10 Ohm |
| Height - Seated (Max) | 0.138 in |
| Inductance | 680 µH |
| Inductance Frequency - Test | 1 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.177 in |
| Size / Dimension Width | 0.157 in |
| Tolerance | 10 % |
| Type | Wirewound |
