RAC06-12SC/W
ObsoleteRecom Power
AC/DC POWER SUPPLY SINGLE-OUT 12V 0.5A 6W 4-PIN BOX
RAC06-12SC/W
ObsoleteRecom Power
AC/DC POWER SUPPLY SINGLE-OUT 12V 0.5A 6W 4-PIN BOX
Description
General part information
RAC06-12SC/W
Enclosed AC DC Converters 1 Output 12V 80 ~ 264 VAC, 115 ~ 370 VDC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | RAC06-12SC/W |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus, CE |
| Current - Output 1 | 500 mA |
| Efficiency | 78 % |
| Features | Universal Input, DC Input Capable |
| Minimum Load Required | Yes |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -25 °C |
| Power (Watts) | 6 W |
| Size / Dimension Height | 0.62 in |
| Size / Dimension Length | 2.11 in |
| Size / Dimension Width | 1.09 in |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 80 V |
| Voltage - Input (DC) Maximum | 370 V |
| Voltage - Input (DC) Minimum | 115 V |
| Voltage - Isolation | 3 kV |
| Voltage - Output 1 | 12 V |
