CSMUAMICB-05M
ActiveUSB CABLE, USB TYPE A PLUG, MICRO USB TYPE B PLUG, 508 MM, 20 ", USB 2.0, BLACK
CSMUAMICB-05M
ActiveUSB CABLE, USB TYPE A PLUG, MICRO USB TYPE B PLUG, 508 MM, 20 ", USB 2.0, BLACK
Description
General part information
CSMUAMICB-05M
The CSMUAMICB-05M is a 0.5m premium USB Cable with type A male to mini-type B 5-position male connectors, PVC jacket and 30μinch (0.762μm) gold. This cable allows for simple plug-and-play connections for devices equipped with mini-USB 5-position ports.
Technical Specifications
Parameters and characteristics for this part
| Specification | CSMUAMICB-05M |
|---|---|
| Color | Black |
| Configuration | A Male to Micro B Male |
| Features | File Transfer Cable |
| Length | 1.64 ft |
| Shielding | Shielded |
| Specifications | USB 2.0 |
| Transfer Rate | 480 Mbps |
| Wire Gauge | 28 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
