2219192-2
ActiveTE Connectivity AMP Connectors
025 16P SLD CAP ASSY
2219192-2
ActiveTE Connectivity AMP Connectors
025 16P SLD CAP ASSY
Description
General part information
2219192-2
16 Position Housing, Housing for Male Terminals, Wire-to-Wire, 2.54 mm [.1 in] Centerline, Sealable, Black, Wire & Cable, Cable Mount (Free-Hanging)
Technical Specifications
Parameters and characteristics for this part
| Specification | 2219192-2 |
|---|---|
| Color | Black |
| Connector Type | Plug |
| Contact Termination | Crimp |
| Contact Type | Tab |
| Fastening Type | Locking Ramp |
| Features | Sealed |
| Mounting Type | Free Hanging (In-Line), Panel Mount |
| Number of Positions | 16 |
| Number of Rows | 2 |
| Pitch | 0.1 in |
| Row Spacing | 0.1 in |
