TERM BLK PLUG 17POS 27.2MM GREEN
1788871
ActivePhoenix Contact
TERM BLK PLUG 17POS 27.2MM GREEN
Description
General part information
1788871
17 Position Terminal Block Green Plug Connection - Ganged 27.2mm
Technical Specifications
Parameters and characteristics for this part
| Specification | 1788871 |
|---|---|
| Current - IEC | 12 A |
| Current - UL | 12 A |
| Height (Max) | 1.181 in |
| Housing Color | Green |
| Length | 3.46 in |
| Material - Insulation | Polyamide, PA, Nylon |
| Material Flammability Rating | UL94 V-2 |
| Mounting Type | DIN Rail |
| Number of Levels | 1 |
| Number of Positions | 17 |
| Stripping Length | 7 mm |
| Terminal Width | 27.2 mm |
| Termination Style | Screw, Plug Receptacles |
| Type | Plug Connection - Ganged |
| Voltage - IEC | 300 V |
| Voltage - UL | 300 V |
| Wire Gauge or Range - AWG (Max) | 30 AWG |
| Wire Gauge or Range - AWG (Min) | 12 AWG |
| Wire Gauge or Range - mm² (Maximum) | 2.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.2 mm² |
