CFM-9232B-230-398-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 92.2X32MM 24VDC WIRE
CFM-9232B-230-398-20
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 92.2X32MM 24VDC WIRE
Description
General part information
CFM-9232B-230-398-20
FAN AXIAL 92.2X32MM 24VDC WIRE
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-9232B-230-398-20 |
|---|---|
| Air Flow | 61.7 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 150 mA |
| Fan Type | Tubeaxial |
| Features | Auto Restart, Speed Sensor (Tach) |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 39.9 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 3.6 W |
| RPM | 3000 RPM |
| Size / Dimension Height | 92.2 mm |
| Size / Dimension Length | 92.2 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.22 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 24 VAC |
| Voltage Range (Max) | 26.4 VDC |
| Voltage Range (Min) | 21.6 VDC |
| Width | 32 mm |
