M20048-EVB-1

Active

Antenova

M20048-1 EVALUATION BOARD

Search across all available documentation for this part.

Active

Antenova

M20048-1 EVALUATION BOARD

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 123.75

General part information

RADIONOVA® MT3337-E GNSS (GPS) 1.575GHz Evaluation Board

Technical documentation and resources

Specification	M20048-EVB-1	M20048 Series

Antenna Connector	-	On-Board, Trace
Applications	-	General Purpose
Current - Receiving	-	31 mA
Data Interface	-	UART
For Use With/Related Products	MT3337-E	MT3337-E
Frequency	1.575 GHz	1.575 GHz
Modulation or Protocol	-	GPS
Mounting Type	-	Surface Mount
Operating Temperature	-	85 °C
Operating Temperature	-	-40 °C
Package / Case	-	Module
Sensitivity	-	-165 dBm
Supplied Contents	Board(s)	Board(s)
Supplier Device Package	-	Module
Type	GNSS (GPS)	GNSS (GPS)
Voltage - Supply	-	3.3 V

Part	Applications	Supplier Device Package	Data Interface	Antenna Connector	Modulation or Protocol	Operating Temperature [Max]	Operating Temperature [Min]	Sensitivity	Package / Case	Voltage - Supply	Current - Receiving	Frequency	Mounting Type	For Use With/Related Products	Supplied Contents	Type
Antenova M20048-1	General Purpose	Module	UART	On-Board, Trace	GPS	85 °C	-40 °C	-165 dBm	Module	3.3 V	31 mA	1.575 GHz	Surface Mount
Antenova M20048-EVB-1												1.575 GHz		MT3337-E	Board(s)	GNSS (GPS)
