125HC1500K2CM6
ActiveCornell Dubilier Knowles
CAP FILM 1.2UF 500VAC CHAS MT
125HC1500K2CM6
ActiveCornell Dubilier Knowles
CAP FILM 1.2UF 500VAC CHAS MT
Description
General part information
125HC1500K2CM6
1.2 µF Film Capacitor 500V Polypropylene (PP) Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | 125HC1500K2CM6 |
|---|---|
| Applications | High Pulse, DV/DT, Conduction Cooled |
| Capacitance | 1.2 µF |
| Dielectric Material | Polypropylene (PP) |
| ESR (Equivalent Series Resistance) | 600 µOhms |
| Height - Seated (Max) | 1.193 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Size / Dimension Length | 2.677 in |
| Size / Dimension Width | 1.181 in |
| Termination | Threaded, Female |
| Tolerance | 10 % |
| Voltage Rating - AC | 500 V |
