LRC30-330M-RC
ActiveAllied Components International
33UH +/-20% LOW RESISTANCE CHIP
LRC30-330M-RC
ActiveAllied Components International
33UH +/-20% LOW RESISTANCE CHIP
Description
General part information
LRC30-330M-RC
33 µH Unshielded Wirewound Inductor 310 mA 1Ohm Max 1812 (4532 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | LRC30-330M-RC |
|---|---|
| Current Rating | 0.31 A |
| DC Resistance (DCR) (Max) | 1 Ohm |
| Frequency - Self Resonant | 12 MHz |
| Height - Seated (Max) | 0.11 in |
| Inductance | 33 µH |
| Inductance Frequency - Test | 1 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 1812 (4532 Metric) |
| Package Name | 1812 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.177 in |
| Size / Dimension Width | 0.126 in |
| Tolerance | 20 % |
| Type | Wirewound |
