Specification	CUS400M-24/C

Applications	ITE (Commercial), Medical
Approval Agency	CE
Current - Output 1	10.42 A
Features	Adjustable Output, Universal Input, Standby Output, Remote Sense
Minimum Load Required	No
Mounting Type	Chassis Mount
Number of Outputs	1
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-20 °C
Power (Watts)	400 W, 250 W
Size / Dimension Height	1.56 in
Size / Dimension Length	5.04 in
Size / Dimension Width	3.05 in
Standard Number	60950-1, 62368-1, 60601-1
Type	Open Frame
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	85 VAC
Voltage - Isolation	4000 Vpk
Voltage - Output 1	24 V

CUS400M Series

Part	Minimum Load Required	Power (Watts)	Size / Dimension Length	Size / Dimension Width	Size / Dimension Height	Type	Operating Temperature (Max)	Operating Temperature (Min)	Features	Mounting Type	Voltage - Isolation	Current - Output 1	Voltage - Output 1	Standard Number	Number of Outputs	Applications	Approval Agency	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum
TDK Corporation CUS400M-48/A	No	250 W 400 W	5.59 in	3.54 in	1.67 in	Enclosed	70 °C	-20 °C	Adjustable Output PFC Remote Sense Universal Input	Chassis Mount	4000 Vpk	5.21 A	48 V	60601-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-24/AX5	No	250 W 400 W	5.59 in	3.54 in	1.67 in	Enclosed	70 °C	-20 °C	Adjustable Output Remote On/Off Remote Sense Standby Output Universal Input	Chassis Mount	4000 Vpk	10.42 A	24 V	60601-1 60950-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-24/A	No	250 W 400 W	5.59 in	3.54 in	1.67 in	Enclosed	70 °C	-20 °C	Adjustable Output Remote Sense Standby Output Universal Input	Chassis Mount	4000 Vpk	10.42 A	24 V	60601-1 60950-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-36/A	No	250 W 400 W	5.59 in	3.54 in	1.67 in	Enclosed	70 °C	-20 °C	Adjustable Output PFC Remote Sense Universal Input	Chassis Mount	4000 Vpk	6.94 A	36 V	60601-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-19/F	No	250 W 400 W	5.59 in	3.54 in	2.66 in	Enclosed	70 °C	-20 °C	Adjustable Output PFC Remote Sense Universal Input	Chassis Mount	4000 Vpk	13.16 A	19 V	60601-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-12/X5	No	250 W 400 W	5.04 in	3.05 in	1.56 in	Open Frame	70 °C	-20 °C	Adjustable Output Remote On/Off Remote Sense Standby Output Universal Input	Chassis Mount	4000 Vpk	20.83 A	12 V	60601-1 60950-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-19/C	No	250 W 400 W	5.57 in	3.36 in	1.61 in	Open Frame	70 °C	-20 °C	Adjustable Output Baseplate PFC Remote Sense Universal Input	Chassis Mount	4000 Vpk	13.16 A	19 V	60601-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-12/F	No	250 W 400 W	5.59 in	3.54 in	2.66 in	Enclosed	70 °C	-20 °C	Adjustable Output Remote Sense Standby Output Universal Input	Chassis Mount	4000 Vpk	20.83 A	12 V	60601-1 60950-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-19/X5		250 W 400 W	5.04 in	3.05 in	1.56 in	Open Frame	70 °C	-20 °C	Adjustable Output PFC Remote On/Off Remote Sense Standby Output Universal Input	Chassis Mount	4000 Vpk	13.16 A	19 V	60601-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
TDK Corporation CUS400M-12/A	No	250 W 400 W	5.59 in	3.54 in	1.67 in	Enclosed	70 °C	-20 °C	Adjustable Output Remote Sense Standby Output Universal Input	Chassis Mount	4000 Vpk	20.83 A	12 V	60601-1 60950-1 62368-1	1	ITE (Commercial) Medical	CE	85 VAC	264 V
