MSDS-04BFFA-SL7001
ActiveMcGill Microwave Systems
CONNECTOR: M12; 4A; 250V; PLUG; FEMALE; PIN: 4; IP67,IP68; STRAIGHT
MSDS-04BFFA-SL7001
ActiveMcGill Microwave Systems
CONNECTOR: M12; 4A; 250V; PLUG; FEMALE; PIN: 4; IP67,IP68; STRAIGHT
Description
General part information
MSDS-04BFFA-SL7001
CONNECTOR: M12; 4A; 250V; PLUG; FEMALE; PIN: 4; IP67,IP68; STRAIGHT
Technical Specifications
Parameters and characteristics for this part
| Specification | MSDS-04BFFA-SL7001 |
|---|---|
| Cable Opening (Max) | 0.256 in |
| Cable Opening (Min) | 0.177 in |
| Color | Silver |
| Connector Type | Female Sockets, Plug |
| Contact Finish - Mating | Gold |
| Current Rating | 4 A |
| Fastening Type | Threaded |
| Features | Coupling Nut, Backshell |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 4 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Orientation | D |
| Primary Material | Metal |
| Shell Material | Metal |
| Shell Size - Insert | M12-4 |
| Shielding | Shielded |
| Termination | Screw |
| Voltage Rating | 250 V |
