Specification	1011558

Applications	ITE (Commercial), Medical
Approval Agency	cURus, UKCA, TUV, CE
Cord Length	39.4 in
Current - Output (Max) Options	8A, 1A
Efficiency	86 %
Form	Desktop (Class I)
Input Connector	IEC 320-C14
Input Type	Cord (Sold Separately)
No Load Power Consumption (Max)	300 mW
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-20 °C
Output Connector	Rectangular
Output Connector Position	14 Position
Power (Watts)	120 W
Region Utilized	International
Size / Dimension Height	2.23 in
Size / Dimension Length	7.78 in
Size / Dimension Width	3.75 in
Standard Number	60601-1, 62368-1
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	85 VAC
Voltage - Output	24 V, 12 V
