Specification	1300610150

1st Connector Gender	Male Pins
1st Connector Mounting Type	Free Hanging (In-Line)
1st Connector Number of Positions	4 positions
1st Connector Number of Positions Loaded	All
1st Connector Orientation	Keyed
1st Connector Shell Size - Insert (Size)	0.875 in
1st Connector Type	Receptacle
2nd Connector Type	Wire Leads
Assembly Configuration	Standard
Cable Material	Polyvinyl Chloride (PVC)
Cable Type	Round
Color	Gray
Ingress Protection Description	Waterproof, Dust Tight
Ingress Protection IP Rating	IP67
Length	6.56 ft
Shielding	Unshielded
Usage	Industrial Environments

130061 Series

Sensor Cables / Actuator Cables BP C 4P M/MP TK ST #12 BK TPE 1.5M

...

Part	Assembly Configuration	1st Connector Orientation	Ingress Protection Description	Ingress Protection IP Rating	Length	1st Connector Type	1st Connector Number of Positions Loaded	Cable Type	Usage	1st Connector Shell Size - Insert (Size)	1st Connector Mounting Type	Shielding	1st Connector Number of Positions	Cable Material	2nd Connector Type	1st Connector Gender	Color	1st Connector Shell Size - Insert	1st Connector Shell Size - Insert (Thread)
Molex 1300611062	Standard	C	Dust Tight Waterproof	IP67	4.92 ft	Receptacle	All	Round	Industrial Environments	0.875 in	Free Hanging (In-Line)	Shielded	4 positions	Thermoplastic Elastomer (TPE)	Wire Leads	Male Pins
Molex 1300611069	Standard	C	Dust Tight Waterproof	IP67	45.9 ft	Receptacle	All	Round	Industrial Environments	0.875 in	Free Hanging (In-Line)	Shielded	4 positions	Thermoplastic Elastomer (TPE)	Wire Leads	Male Pins
Molex 1300610192	Standard	A	Dust Tight Waterproof	IP67	59.1 ft	Receptacle Right Angle	All	Round	Industrial Environments	0.875 in	Free Hanging (In-Line)	Unshielded	4 positions	Polyvinyl Chloride (PVC)	Wire Leads	Male Pins	Gray
Molex 1300611055	Standard		Dust Tight Waterproof	IP67	32.8 ft	Plug	All	Round	Industrial Environments	0.875 in	Free Hanging (In-Line)	Shielded	4 positions	Polyvinyl Chloride (PVC)	Wire Leads	Female Sockets	Black
Molex 1300611079
Molex 1300610122	Standard		Dust Tight Waterproof	IP67	16.4 ft	Plug Right Angle	All	Round			Free Hanging (In-Line)	Unshielded	4 positions	Polyvinyl Chloride (PVC)	Wire Leads	Female Sockets	Gray	A
Molex 1300611096	Standard	A	Dust Tight Waterproof	IP67	16.4 ft	Plug	All	Round	Industrial Environments	0.875 in	Free Hanging (In-Line)	Unshielded	3 positions	Thermoplastic Elastomer (TPE)	Wire Leads	Female Sockets	Black
Molex 1300610153	Standard	A	Dust Tight Waterproof	IP67	13.12 ft	Receptacle	All	Round	Industrial Environments	0.875 in	Free Hanging (In-Line)	Unshielded	4 positions	Polyvinyl Chloride (PVC)	Wire Leads	Male Pins	Gray
Molex 1300610236
Molex 1300610217	Standard		Dust Tight Waterproof	IP67	13.12 ft	Plug	All	Round	Industrial Environments	0.875 in	Free Hanging (In-Line)	Unshielded	3 positions	Polyvinyl Chloride (PVC)	Wire Leads	Female Sockets	Gray		M22
