76 Series

DIP Switches / SIP Switches DIP Switch, SPST, recessed rocker, 3 position, w/line, RoHS Compliant

Part	Length	Body Material	Electrical Life (Cycles)	Mechanical Life (Cycles)	Contact Finish	Washable	Mounting Type	Termination Style	Circuit	Operating Temperature (Min)	Operating Temperature (Max)	Current Rating	Height Above Board	Number of Positions	Actuator Type	Contact Material	Voltage Rating	Actuator Level	Pitch	Pitch Type	Features
Grayhill Inc. 76PRB05T	0.58 in	Thermoplastic	2000 Cycles	2000 Cycles	Gold	No	Right Angle Through Hole	PC Pin	SPST	-40 °C	85 °C	150 mA	0.301 in	5	Piano	Copper Alloy	30 V	Raised	0.1 in	Full
Grayhill Inc. 76PRB10ST	1.08 in	Thermoplastic	2000 Cycles	2000 Cycles	Gold	Yes	Right Angle Through Hole	PC Pin	SPST	-40 °C	85 °C	150 mA	0.301 in	10	Piano	Copper Alloy	30 V	Raised	0.1 in	Full	Tape Seal
Grayhill Inc. 76PRB04T	0.48 in	Thermoplastic	2000 Cycles	2000 Cycles	Gold	No	Right Angle Through Hole	PC Pin	SPST	-40 °C	85 °C	150 mA	0.301 in	4	Piano	Copper Alloy	30 V	Raised	0.1 in	Full

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.
