DGBV15MF
ActivePasternack
ADPT VGA SKT SAVER HD15M/F
DGBV15MF
ActivePasternack
ADPT VGA SKT SAVER HD15M/F
Description
General part information
DGBV15MF
Adapter Connector D-Sub, 15 Pin Male To D-Sub, 15 Pin Female Free Hanging (In-Line)
Technical Specifications
Parameters and characteristics for this part
| Specification | DGBV15MF |
|---|---|
| Connector Style | Connector Saver |
| Contact Finish | Gold |
| Contact Finish Thickness | 0 |
| Contact Finish Thickness | Flash |
| Contact Finish Thickness (string set options) | Flash |
| Convert From (Adapter End) Pin Count | 15 pins |
| Convert From (Adapter End) Pin Gender | Female |
| Convert From (Adapter End) Type | D-Sub |
| Convert To (Adapter End) | Pin Male, D-Sub |
| Convert To (Adapter End) Pin Count | 15 pins |
| Current Rating | 3 A |
| Features | Grounding Indents |
| Finish | Tin-Nickel Plated |
| Housing Color | Blue |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Rows | 2 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Shell Material | Steel |
| Shielding | Shielded |
