SQ4120-1R0MHF
ActiveITG Electronics, Inc.
1.0UH, 0.95MOHM, 12.5A MAX. FLAT
SQ4120-1R0MHF
ActiveITG Electronics, Inc.
1.0UH, 0.95MOHM, 12.5A MAX. FLAT
Description
General part information
SQ4120-1R0MHF
1 µH Drum Core, Wirewound Inductor 23 A 0.95mOhm 3-SMD
Technical Specifications
Parameters and characteristics for this part
| Specification | SQ4120-1R0MHF |
|---|---|
| Current - Saturation (Isat) | 12.5 A |
| Current Rating | 23 A |
| DC Resistance (DCR) | 0.95 mOhm |
| Height - Seated (Max) | 0.197 in |
| Inductance | 1 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 130 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 3-SMD |
| Package Name | 3-SMD |
| Size / Dimension Length | 0.406 in |
| Size / Dimension Width | 0.319 in |
| Tolerance | 20 % |
| Type | Drum Core, Wirewound |
