CFM-6020B-140-320
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 60X20MM 12VDC WIRE
CFM-6020B-140-320
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 60X20MM 12VDC WIRE
Description
General part information
CFM-6020B-140-320
Fan Tubeaxial 12VDC Square - 60mm L x 60mm H Ball 15.2 CFM (0.426mł/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-6020B-140-320 |
|---|---|
| Air Flow | 15.2 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 120 mA |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 32 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 1.44 W |
| RPM | 4000 RPM |
| Size / Dimension Height | 60 mm |
| Size / Dimension Length | 60 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.12 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 12 VAC |
| Voltage Range (Max) | 13.2 VDC |
| Voltage Range (Min) | 10.8 VDC |
| Width | 20 mm |
