PEWM5930FL800K9
ActiveC&B Eureka Innovations
0.0008 OHMS 1% 7W 100PPM/C
PEWM5930FL800K9
ActiveC&B Eureka Innovations
0.0008 OHMS 1% 7W 100PPM/C
Description
General part information
PEWM5930FL800K9
800 µOhms ±1% 9W Chip Resistor Nonstandard Current Sense Metal Element
Technical Specifications
Parameters and characteristics for this part
| Specification | PEWM5930FL800K9 |
|---|---|
| Composition | Metal Element |
| Features | Current Sense |
| Height - Seated (Max) | 0.054 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 170 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Package Name | 5930 |
| Power (Watts) | 9 W |
| Resistance | 800 µOhms |
| Size / Dimension Length | 0.591 in |
| Size / Dimension Width | 0.305 in |
| Temperature Coefficient | 100 ppm/°C |
| Tolerance | 1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
