B25645A1567K003
ActiveEPCOS - TDK Electronics
MODULAR DCR 560UF - 1800V - 140A
B25645A1567K003
ActiveEPCOS - TDK Electronics
MODULAR DCR 560UF - 1800V - 140A
Description
General part information
B25645A1567K003
535 µF Film Capacitor 1800V (1.8kV) Polypropylene (PP) Module
Technical Specifications
Parameters and characteristics for this part
| Specification | B25645A1567K003 |
|---|---|
| Applications | DC Filtering, DC Link |
| Capacitance | 535 µF |
| Dielectric Material | Polypropylene (PP) |
| Height - Seated (Max) | 6.752 in |
| Mounting Type | Chassis Mount |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Module |
| Size / Dimension Length | 8.071 in |
| Size / Dimension Width | 3.543 in |
| Termination | Connector |
| Tolerance | 10 % |
| Voltage Rating - DC | 1800 V |
