DCM232315H-203NHF
ActiveITG Electronics, Inc.
20,000UH,520MOHM, 0.7AMP DIP CMC
DCM232315H-203NHF
ActiveITG Electronics, Inc.
20,000UH,520MOHM, 0.7AMP DIP CMC
Description
General part information
DCM232315H-203NHF
20 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 700mA DCR 520mOhm
Technical Specifications
Parameters and characteristics for this part
| Specification | DCM232315H-203NHF |
|---|---|
| Current Rating (Max) | 700 mA |
| DC Resistance (DCR) (Max) | 520 mOhm |
| Filter Type | Power Line |
| Height (Max) | 0.61 in |
| Inductance | 20 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature (Max) | 130 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 4 PC Pin, Horizontal |
| Package Leads | 4 Leads |
| Package Name | Horizontal |
| Size / Dimension Length | 0.906 in |
| Size / Dimension Width | 0.906 in |
