Description
General part information
AMES100-5SNZ
Enclosed AC DC Converters 1 Output 5V 85 ~ 264 VAC, 120 ~ 373 VDC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | AMES100-5SNZ |
|---|---|
| Applications | ITE (Commercial), Household Appliances |
| Approval Agency | cURus |
| Current - Output 1 | 18 A |
| Efficiency | 86 % |
| Features | DC Input Capable, Universal Input, Adjustable Output |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -30 °C |
| Power (Watts) | 90 W |
| Size / Dimension Height | 1.18 in |
| Size / Dimension Length | 5.08 in |
| Size / Dimension Width | 3.82 in |
| Standard Number | 60335-1, 62368-1 |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 85 VAC |
| Voltage - Input (DC) Maximum | 373 VDC |
| Voltage - Input (DC) Minimum | 120 V |
| Voltage - Isolation | 4000 Vpk |
| Voltage - Output 1 | 5 V |
