MAL218597508E3
ActiveVishay Dale
CAP ALUM POLY 220UF 20% 16V SMD
MAL218597508E3
ActiveVishay Dale
CAP ALUM POLY 220UF 20% 16V SMD
Description
General part information
MAL218597508E3
220 µF 16 V Aluminum - Polymer Capacitors Radial, Can - SMD 18mOhm 5000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MAL218597508E3 |
|---|---|
| Applications | General Purpose |
| Capacitance | 220 µF |
| ESR (Equivalent Series Resistance) | 18 mOhm |
| Height - Seated (Max) | 0.472 in |
| Lifetime | 5000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial, Can - SMD |
| Ripple Current | 4.2 A, 210 mA |
| Size / Dimension Diameter | 0.315 in |
| Surface Mount Land Length | 0.327 in |
| Surface Mount Land Width | 0.327 in |
| Tolerance | 20 % |
| Type | Polymer |
| Voltage - Rated | 16 V |
