CFM-9238BF-180-585
ActiveSame Sky (Formerly CUI Devices)
DC FANS DC AXIAL FAN, 92 MM SQUARE, 38 MM, 12 VDC, BALL, 8000 RPM, 108.91 CFM
CFM-9238BF-180-585
ActiveSame Sky (Formerly CUI Devices)
DC FANS DC AXIAL FAN, 92 MM SQUARE, 38 MM, 12 VDC, BALL, 8000 RPM, 108.91 CFM
Description
General part information
CFM-9238BF-180-585
Fan Tubeaxial 12VDC Square - 92mm L x 92mm H Ball 108.9 CFM (3.05m³/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-9238BF-180-585 |
|---|---|
| Air Flow | 108.9 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Ball |
| Current Rating | 1.14 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 58.5 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 13.68 W |
| RPM | 8000 RPM |
| Size / Dimension Height | 92 mm |
| Size / Dimension Length | 92 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 1.64 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 12 VAC |
| Voltage Range (Max) | 13.2 VDC |
| Voltage Range (Min) | 10.8 VDC |
| Width | 38 mm |
