PFC250-1012
ObsoleteBel Fuse Inc.
AC/DC CONVERTER 12V 250W
PFC250-1012
ObsoleteBel Fuse Inc.
AC/DC CONVERTER 12V 250W
Description
General part information
PFC250-1012
Enclosed AC DC Converters 1 Output 12V 85 ~ 264 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | PFC250-1012 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output 1 | 23 A |
| Efficiency | 75 % |
| Features | Adjustable Output, Universal Input, Remote Sense, PFC |
| Minimum Load Required | No |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 250 W |
| Size / Dimension Height | 2 in |
| Size / Dimension Length | 8.5 in |
| Size / Dimension Width | 4.75 in |
| Type | Enclosed |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 85 VAC |
| Voltage - Isolation | 2600 Vrms |
| Voltage - Output 1 | 12 V |
