2337857-1
ActiveTE Connectivity AMP Connectors
VERTICAL USB TYPE-C REC
2337857-1
ActiveTE Connectivity AMP Connectors
VERTICAL USB TYPE-C REC
Description
General part information
2337857-1
C, 3.1 Gen 1, Standard Profile, Receptacle, Top, Vertical, Tape & Reel, Surface Mount, Cable-to-Board, Printed Circuit Board, USB Connectors
Technical Specifications
Parameters and characteristics for this part
| Specification | 2337857-1 |
|---|---|
| Connector Type | USB-C (USB TYPE-C) |
| Current Rating Options | 1.5A, 0.25A, 1A |
| Gender | Receptacle |
| Mating Cycles | 10000 cycles |
| Mounting Feature | Vertical |
| Mounting Type | Surface Mount, Through Hole |
| Number of Contacts | 24 |
| Number of Ports | 1 |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -40 °C |
| Shielding | Shielded |
| Specifications | Superspeed (USB 3.0), USB 3.1 Gen 1, USB 3.2 Gen 1 |
| Termination | Solder |
| Voltage - Rated | 30 VAC |
