MAL225972152E3
ActiveVishay Dale
CAP ALUM 1500UF 20% 200V SNAP TH
MAL225972152E3
ActiveVishay Dale
CAP ALUM 1500UF 20% 200V SNAP TH
Description
General part information
MAL225972152E3
1500 µF 200 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 3 Lead 100mOhm @ 100Hz 3000 Hrs @ 105°C
Technical Specifications
Parameters and characteristics for this part
| Specification | MAL225972152E3 |
|---|---|
| Applications | General Purpose |
| Capacitance | 1500 µF |
| ESR (Equivalent Series Resistance) | 100 mOhm |
| Height - Seated (Max) | 1.85 in |
| Impedance | 70 mOhms |
| Lead Spacing | 0.394 in |
| Lifetime | 3000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 3 Leads |
| Package Name | Radial, Can - Snap-In |
| Polarization | Polar |
| Ripple Current | 5.37 A, 3.58 A |
| Size / Dimension Diameter | 1.181 in |
| Tolerance | 20 % |
| Voltage - Rated | 200 VDC |
