SLSR30-300Q8
ActiveBANNER ENGINEERING
SLSR30-300Q8 EZ-SCREEN RECEIVER;
SLSR30-300Q8
ActiveBANNER ENGINEERING
SLSR30-300Q8 EZ-SCREEN RECEIVER;
Description
General part information
SLSR30-300Q8
Light Curtain 30mm Hand/Arm Receiver Only
Technical Specifications
Parameters and characteristics for this part
| Specification | SLSR30-300Q8 |
|---|---|
| Detection Capability | 30 mm |
| Features | Receiver Only |
| Ingress Protection Description | Dust Tight, Water Resistant |
| Ingress Protection IP Rating | IP65 |
| Number of Beams | 20 |
| Operating Range (Max) | 18 m |
| Operating Range (Min) | 0.1 m |
| Operating Temperature (Max) | 55 °C |
| Operating Temperature (Min) | 0 °C |
| Protection | Hand/Arm |
| Protective Height | 300 mm |
| Voltage - Supply | 24 VDC |
