8203
Active3M Electronic Specialty
CONN FIBER FC PLUG SMPLX 126UM
8203
Active3M Electronic Specialty
CONN FIBER FC PLUG SMPLX 126UM
Description
General part information
8203
Fiber Optic Plug Connector FC Simplex 126µm Silver
Technical Specifications
Parameters and characteristics for this part
| Specification | 8203 |
|---|---|
| Attenuation (Typical) | -0.3 dB |
| Body Material | Nickel Plated, Zinc |
| Boot Color | White |
| Cable Diameter | 0.9 mm |
| Connector Style | FC |
| Connector Type | Plug |
| Fastening Type | Threaded |
| Features | Strain Relief |
| Ferrule Material | Zirconia |
| Fiber Cladding Diameter | 126 µm |
| Housing Color | Silver |
| Mating Cycles | 500 cycles |
| Mode | Singlemode |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Reflection | -45 dB |
| Simplex/Duplex | Simplex |
