M8AS-04BFFM-SL7D02
ActiveMcGill Microwave Systems
CIRC CBL 4POS PLUG TO WIRE 6.56'
M8AS-04BFFM-SL7D02
ActiveMcGill Microwave Systems
CIRC CBL 4POS PLUG TO WIRE 6.56'
Description
General part information
M8AS-04BFFM-SL7D02
Circular Cable Assembly Unshielded 6.56' (2.00m)
Technical Specifications
Parameters and characteristics for this part
| Specification | M8AS-04BFFM-SL7D02 |
|---|---|
| 1st Connector Gender | Female Sockets |
| 1st Connector Mounting Type | Free Hanging (In-Line) |
| 1st Connector Number of Positions | 4 positions |
| 1st Connector Number of Positions Loaded | All |
| 1st Connector Orientation | A |
| 1st Connector Shell Size - Insert | M8 |
| 1st Connector Type | Plug |
| 2nd Connector Type | Wire Leads |
| Assembly Configuration | Standard |
| Cable Material | Polyvinyl Chloride (PVC) |
| Cable Type | Round |
| Color | Black |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Length | 6.56 ft |
| Shielding | Unshielded |
| Usage | Industrial Environments |
