Specification	XCKJ10559D

Actuator Type	Adjustable Rod, Side Rotary
Circuit	DPST-NO/NC
Current Rating	3 A, 270 mA
Electrical Life (Cycles)	5000000 Cycles
Ingress Protection Description	Dust Tight, Water Resistant
Ingress Protection IP Rating	IP66
Mechanical Life (Cycles)	30000000 Cycles
Mounting Type	Chassis Mount
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-25 °C
Switch Function	On-Mom, Off-Mom
Termination Style	Connector
Voltage Rating - AC	50 VAC
Voltage Rating - DC	50 V
