QAS254K600D022
ActiveCornell Dubilier Knowles
0.25UF, 600, 36.8X10.6X19, 22
QAS254K600D022
ActiveCornell Dubilier Knowles
0.25UF, 600, 36.8X10.6X19, 22
Description
General part information
QAS254K600D022
RC EMI Filter 1st Order RC Snubber Network Channel R = 22Ohms, C = 0.25µF Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | QAS254K600D022 |
|---|---|
| Applications | RFI Suppression, EMI, DV/DT, Snubber, High Pulse |
| Capacitance | 0.25 µF |
| Filter Order | 1 |
| Height | 0.75 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Resistance | 22 Ohm |
| Size / Dimension Length | 1.45 in |
| Size / Dimension Width | 0.42 in |
| Technology | RC |
| Type | RC Snubber Network |
| Voltage - Rated | 600 V |
