OPB742
ActiveTT Electronics/BI
OPTICAL SWITCHES, REFLECTIVE, PHOTOTRANSISTOR OUTPUT EMMITER/SENSOR ASSEM
OPB742
ActiveTT Electronics/BI
OPTICAL SWITCHES, REFLECTIVE, PHOTOTRANSISTOR OUTPUT EMMITER/SENSOR ASSEM
Description
General part information
OPB742
Reflective Optical Sensor 0.150" (3.81mm) PCB Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | OPB742 |
|---|---|
| Current - DC Forward (If) (Max) | 40 mA |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 80 °C |
| Operating Temperature (Min) | -40 °C |
| Output Type | Phototransistor |
| Package / Case | PCB Mount |
| Sensing Distance | 0.15 " |
| Sensing Method | Reflective |
| Voltage - Collector Emitter Breakdown (Max) | 30 V |
