WBFK-30019-000
ActiveKnowles Syfer
SPEAKER 15.2OHM TOP PORT 91DB
WBFK-30019-000
ActiveKnowles Syfer
SPEAKER 15.2OHM TOP PORT 91DB
Description
General part information
WBFK-30019-000
15.2 Ohms Receiver, Balanced Armature Speaker 200 Hz ~ 7.7 kHz Top Rectangular
Technical Specifications
Parameters and characteristics for this part
| Specification | WBFK-30019-000 |
|---|---|
| Efficiency - dBA | 91 dBA |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Frequency Range (Max) | 7.7 kHz |
| Frequency Range (Min) | 200 Hz |
| Height - Seated (Max) | 0.26 in |
| Impedance | 15.2 Ohms |
| Port Location | Top |
| Shape | Rectangular |
| Size / Dimension Length | 0.197 in |
| Size / Dimension Width | 0.108 in |
| Technology | Magnetic |
| Termination | Solder Pads |
| Type | Balanced Armature, Receiver |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
