MU10-250DMX-BOTTLE
Active3M Electronic Specialty
CONN QC TAB 10-12AWG 0.250 50PC
MU10-250DMX-BOTTLE
Active3M Electronic Specialty
CONN QC TAB 10-12AWG 0.250 50PC
Description
General part information
MU10-250DMX-BOTTLE
CONN QC TAB 10-12AWG 0.250 50PC
Technical Specifications
Parameters and characteristics for this part
| Specification | MU10-250DMX-BOTTLE |
|---|---|
| Contact Finish | Tin |
| Contact Material | Copper |
| Features | Butted Seam |
| Gender | Male |
| Insulation | Non-Insulated |
| Length - Overall | 0.75 in |
| Mounting Type | Free Hanging (In-Line) |
| Tab Thickness | 0.032 in |
| Tab Width | 0.25 in |
| Terminal Type | Standard |
| Termination | Crimp |
| Wire Gauge (AWG) (Max) | 12 AWG |
| Wire Gauge (AWG) (Min) | 10 AWG |
