450-0064R
ObsoleteEzurio LLC
RF TXRX MOD BT WIFIU.FL SMD
450-0064R
ObsoleteEzurio LLC
RF TXRX MOD BT WIFIU.FL SMD
Description
General part information
450-0064R
RF TXRX MOD BT WIFIU.FL SMD
Technical Specifications
Parameters and characteristics for this part
| Specification | 450-0064R |
|---|---|
| Antenna Type | Antenna Not Included, U.FL |
| Current - Receiving (Max) | 100 mA |
| Current - Receiving (Min) | 35 mA |
| Current - Transmitting (Max) | 280 mA |
| Current - Transmitting (Min) | 43 mA |
| Data Rate | 65 Mbps |
| Frequency | 2.4 GHz |
| Modulation | CCK, OFDM, GMSK, GFSK |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Module |
| Power - Output | 20 dBm |
| Protocol | 802.11g, Bluetooth v4.0 Dual Mode, 802.11b, 802.11n |
| RF Family/Standard | WiFi, Bluetooth |
| Sensitivity | -97 dBm |
| Serial Interfaces | UART, I2S, SDIO |
| Utilized IC / Part | WL1271L |
| Voltage - Supply (Maximum) | 4.8 V |
| Voltage - Supply (Minimum) | 3 V |
