Specification	LC4128V-75TN144E

Delay Time tpd(1) Max	7.5 ns
Mounting Type	Surface Mount
Number of I/O	96
Number of Logic Elements/Blocks	8
Number of Macrocells	128
Operating Temperature (Max)	130 °C
Operating Temperature (Min)	-40 °C
Package / Case	144-LQFP
Package Length	20 mm
Package Name	144-TQFP
Package Width	20 mm
Programmable Type	In System Programmable
Voltage Supply - Internal (Maximum)	3.6 V
Voltage Supply - Internal (Minimum)	3 V

LC4128 Series

Part	Delay Time tpd(1) Max	Programmable Type	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	Voltage Supply - Internal (Maximum)	Voltage Supply - Internal (Minimum)	Number of Logic Elements/Blocks	Number of Macrocells	Package Width	Package Name	Package Length	Mounting Type	Number of I/O
Lattice Semiconductor Corporation LC4128C-5T100C	5 ns	In System Programmable	100-LQFP	0 °C	90 °C	1.95 V	1.65 V	8	128	14 mm	100-TQFP	14 mm	Surface Mount	64
Lattice Semiconductor Corporation LC4128B-10TN100I	10 ns	In System Programmable	100-LQFP	-40 °C	105 °C	2.7 V	2.3 V	8	128	14 mm	100-TQFP	14 mm	Surface Mount	64
Lattice Semiconductor Corporation LC4128ZC-75MN132C	7.5 ns	In System Programmable	132-LFBGA CSPBGA	0 °C	90 °C	1.9 V	1.7 V	8	128	8 mm	132-CSBGA	8 mm	Surface Mount	96
Lattice Semiconductor Corporation LC4128ZE-5MN144C	5.8 ns	In System Programmable	144-TFBGA CSPBGA	0 °C	90 °C	1.9 V	1.7 V	8	128	7 mm	144-CSBGA	7 mm	Surface Mount	96
Lattice Semiconductor Corporation LC4128V-5TN128I	5 ns	In System Programmable	128-LQFP	-40 °C	105 °C	3.6 V	3 V	8	128	14 mm	128-TQFP	14 mm	Surface Mount	92
Lattice Semiconductor Corporation LC4128V-75T144E	7.5 ns	In System Programmable	144-LQFP	-40 °C	130 °C	3.6 V	3 V	8	128	20 mm	144-TQFP	20 mm	Surface Mount	96
Lattice Semiconductor Corporation LC4128V-27T128C	2.7 ns	In System Programmable	128-LQFP	0 °C	90 °C	3.6 V	3 V	8	128	14 mm	128-TQFP	14 mm	Surface Mount	92
Lattice Semiconductor Corporation LC4128V-75T100E	7.5 ns	In System Programmable	100-LQFP	-40 °C	130 °C	3.6 V	3 V	8	128	14 mm	100-TQFP	14 mm	Surface Mount	64
Lattice Semiconductor Corporation LC4128V-75TN144I	7.5 ns	In System Programmable	144-LQFP	-40 °C	105 °C	3.6 V	3 V	8	128	20 mm	144-TQFP	20 mm	Surface Mount	96
Lattice Semiconductor Corporation LC4128V-75TN100E	7.5 ns	In System Programmable	100-LQFP	-40 °C	130 °C	3.6 V	3 V	8	128	14 mm	100-TQFP	14 mm	Surface Mount	64
