Part	1st Connector	1st Connector Power Positions	1st Connector Dimmable Positions	1st Connector Positions	2nd Connector	Color	Features	Current Rating	Voltage Rating	Mounting Type	Housing Color	Wire Gauge (AWG) (Max)	Wire Gauge (AWG) (Min)	Contact Material	Style	Connector Type	Contact Finish	Operating Temperature (Min)	Operating Temperature (Max)	Housing Material	Number of Positions	Termination	Wire Gauge	Length
TE Connectivity AMP Connectors 2213899-2	3 Power) 7 Position (4 Dimmable Socket	3	4	7 7 Numeric	Wire Leads	Individual Multiple	Dimming
TE Connectivity AMP Connectors 2213899-1	3 Power) 5 Position (2 Dimmable Socket	3	2	5	Wire Leads	Individual Multiple	Dimming
TE Connectivity AMP Connectors 2376865-3								15 A	600 V	Panel Mount	Black	18 AWG	14 AWG	Copper Alloy	Board Cable/Wire	Receptacle	Gold	-40 °C	105 °C	Glass Filled Thermoplastic	5	Poke-In
TE Connectivity AMP Connectors 2376865-1										Panel Mount	Black	18 AWG	14 AWG	Copper Alloy	Board Cable/Wire	Receptacle	Gold	-40 °C	85 °C	Glass Filled Thermoplastic	2	Poke-In
TE Connectivity AMP Connectors 2439396-2										Panel Mount	Black			Copper Alloy	Board Cable/Wire	Receptacle	Gold	-40 °C	85 °C	Glass Filled Thermoplastic	3	Poke-In	18 AWG
TE Connectivity AMP Connectors 4-2213362-4	3 Power) 7 Position (4 Dimmable Socket	3	4	7 7 Numeric	Wire Leads	Individual Multiple	Dimming																	36 in
TE Connectivity AMP Connectors 2439396-1										Panel Mount	Black			Copper Alloy	Board Cable/Wire	Receptacle	Gold	-40 °C	85 °C	Glass Filled Thermoplastic	7	Poke-In	18 AWG
TE Connectivity AMP Connectors 1-2213362-4	3 Position Socket			3	Wire Leads	Individual Multiple	Dimming																	19.7 in
TE Connectivity AMP Connectors 2213899-3	3 Power) 5 Position (2 Dimmable Socket	3	2	5	Wire Leads	Individual Multiple	Dimming
TE Connectivity AMP Connectors 2376865-5										Panel Mount	Black	18 AWG	14 AWG	Copper Alloy	Board Cable/Wire	Receptacle	Gold	-40 °C	105 °C	Glass Filled Thermoplastic	3	Poke-In
