GLC65-5G
ObsoleteSL POWER / Advanced Energy
AC/DC CONVERTER 5.1V 65W
GLC65-5G
ObsoleteSL POWER / Advanced Energy
AC/DC CONVERTER 5.1V 65W
Description
General part information
GLC65-5G
Open Frame AC DC Converters 1 Output 5.1V 90 ~ 264 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | GLC65-5G |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cURus, TUV, CE |
| Current - Output 1 | 11 A |
| Efficiency | 80 % |
| Features | Universal Input, Adjustable Output, Remote Sense |
| Minimum Load Required | No |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 65 W |
| Size / Dimension Height | 1.25 in |
| Size / Dimension Length | 5 in |
| Size / Dimension Width | 3 in |
| Type | Open Frame |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Output 1 | 5.1 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
